Name: CE5855-24T4S2Q-EI 24 10/100/1000BASE-T 4 10GE SFP And 2 40GE QSFP Switch and Ready
Brand: Beijing Yongchang Gaotai Technology Development Co., Ltd.
SKU: CE5855-24T4S2Q-EI Switch
Availability: InStock

Detail Information

Private Mold:	NO	Products Status:	Stock, Used, Stock
Ports:	≥ 48	Transmission Rate:	10/100/1000Mbps
Function:	LACP, SNMP	Communication Mode:	Full-Duplex & Half-Duplex
Switch Capacity:	56 Gb/s	Product Name:	CE5855-24T4S2Q-EI Switch
Type:	Rack

Product Description

Products Description

CE5855-24T4S2Q-EI Overview

Huawei CE5855-24T4S2Q-EI Switch(24-Port GE RJ45,4-Port 10G SFP+,2-Port 40G QSFP+,Without Fan and Power Module).

Huawei CloudEngine 5800 series (CE5800) switches are next-generation, high-density Gigabit Ethernet switches designed for data centers and high-end campus networks. The CE5800 hardware has an advanced architectural design with the industry's highest density of GE access ports. The CE5800 is also the first Gigabit Ethernet access switch to provide 40GE uplink ports. Using the Huawei VRP8 software platform, CE5800 switches support Transparent Interconnection of Lots of Links (TRILL) and have a high stacking capability (up to 16-member switches in a stack system).

Quick Spec

Table 1 shows the quick spec.

Model	CE5855-24T4S2Q-EI
Relative humidity	5% RH to 95% RH, noncondensing
Altitude	< 5000 m (16404 ft.)
Power source type	AC/DC
AC power input	Rated input voltage range: 100 V AC to 240 V AC, 50/60 Hz
DC power input	Rated voltage range: -48 V DC to -60 V DC
High-voltage DC power input	Not supported
Maximum power consumption	75 W
Typical power consumption	48 W (100% throughput, 3 m Ethernet cables on 24 ports and SFP+ cables on 4 ports and QSFP+ cables on 2 ports, double power modules)
Maximum heat dissipation	256 BTU/hr
Typical heat dissipation	164 BTU/hr (100% throughput, 3 m Ethernet cables on 24 ports and SFP+ cables on 4 ports and QSFP+ cables on 2 ports, double power modules)
Heat dissipation mode	Air cooling
Airflow	Front-to-back or back-to-front, depending on the fan modules and power modules
Power module backup	1+1 backup
Fan module backup	1+1 backup not supported
Hot swap	Supported by all power modules and fan modules
Processor	1 GHz, dual-core
DRAM Memory	2 GB
NOR Flash	16 MB
NAND Flash	512 MB
Service port supporting the stack function	10GE optical ports and 40GE optical ports

CE5855-24T4S2Q-EI Specification

CE5855-24T4S2Q-EI Specification
Model	CE5855-24T4S2Q-EI
Relative humidity	5% RH to 95% RH, noncondensing
Altitude	< 5000 m (16404 ft.)
Power source type	AC/DC
AC power input	Rated input voltage range: 100 V AC to 240 V AC, 50/60 Hz
DC power input	Rated voltage range: -48 V DC to -60 V DC
High-voltage DC power input	Not supported
Maximum power consumption	75 W
Typical power consumption	48 W (100% throughput, 3 m Ethernet cables on 24 ports and SFP+ cables on 4 ports and QSFP+ cables on 2 ports, double power modules)
Maximum heat dissipation	256 BTU/hr
Typical heat dissipation	164 BTU/hr (100% throughput, 3 m Ethernet cables on 24 ports and SFP+ cables on 4 ports and QSFP+ cables on 2 ports, double power modules)
Heat dissipation mode	Air cooling
Airflow	Front-to-back or back-to-front, depending on the fan modules and power modules
Power module backup	1+1 backup
Fan module backup	1+1 backup not supported
Hot swap	Supported by all power modules and fan modules
Processor	1 GHz, dual-core
DRAM Memory	2 GB
NOR Flash	16 MB
NAND Flash	512 MB
Service port supporting the stack function	10GE optical ports and 40GE optical ports

Contact Information:
Vicky
Wechat/Whatsapp: +86 13161893918
Skype/Email: vickyjing@yongchangtech.cn

Tag:

Place of Origin:	Fujian, China
Brand Name:	H3C
Model Number:	CE5855-24T4S2Q-EI Switch

Minimum Order Quantity:	1 unit
Price:	$5,000.00/pieces 1-9 pieces
